LUTRON LX-113S LUX METER
LUTRON LX-113S LUX METER
LUTRON LX-113S LUX METER adalah alat ukur intensitas cahaya (light meter / lux meter) digital portabel yang dilengkapi fitur auto-ranging untuk kemudahan operasional. Alat buatan Taiwan ini dirancang untuk mengukur tingkat iluminasi di lingkungan kerja, laboratorium, pabrik, maupun kebutuhan fotografi.
Features Lutron LX-113S Light Meter
- 2,000/20,000/50,000 Lux , Autorange
- Light sensor used the exclusive photo diode & color correction filter, spectrum meet C.I.E. photopic
- Light sensor cosine correction factor meet standard
- Separate Light Sensor allows user to measure the light at an optimum position
- Light meter can default the display unit to Lux or Ft-cd with default
- Zero key function
- Sepeare light probe, easy operation
- Microprocessor circuit
- DC 9V battery ( 006 P )
- Microcomputer circuit provides high accuracy
- Data hold function for freezing the desired value
- Built-in low battery indicator
Specifications Lutron LX-113S Light Meter
- Measurement range:
- LUX:
- 0 to 1,999 LUX, Resolution 1
- 2,000 to 19,990 LUX, Resolution 10
- 20,000 to 50,000 LUX, Resolution 100
- Foot-Candles (FC):
- 0 to 1.99 FC, Resolution 0.1
- 200 to 1,999 FC, Resolution 1
- 2,000 to 5,000 FC, Resolution 10
- LUX:
- Accuracy is within: plus or minus (5% + 4 digits)
- Sampling time: approximately 1 second
- Display: 0.5″ LCD, 3 1/2 digits, Max indication 1999
- Sensor: exclusive photo diode & color correction filter
- Operating humidity range: less than 80%, non condensing
- Operating temperature range: 32° to 122° F (0° to 50° C)
- Weight: approximately 7ounces (195 grams) with battery installed
- Power supply: (1) 9v alkaline battery
- Power current: approximately DC 2.7mA
- Dimensions:
- Meter: 5.3″ x 2.4″ x 1.3″ (135 x 60 x 33 mm)
- Sensor probe: 3.2″ x 2.2″ x 0.3″ (82 x 55 x 7 mm)
Electrical Specifications (23± 5 )
-
LUX @ auto range
Range : In-range Display : Resolution : Accuracy
2,000 LUX : 0-1,999 LUX : 1 LUX : ± ( 5 % + 4 LUX )
20,000 LUX : 2,000-19,990 LUX : 10 LUX : ± ( 5 % + 40 LUX )
50,000 LUX : 20,000-50,000 LUX : 100 LUX : ± ( 5 % + 400 LUX ) -
Feet-candle ( Ft-cd ) @ auto range
Range : In-range Display : Resolution : Accuracy
200 FC : 0-199.9 Ft-cd : 0.1 FC : ± ( 5 % + 0.4 FC )
2,000 FC : 200-1,999 : Ft-cd 1 FC : ± ( 5 % + 4 FC )
5,000 FC : 2,000-5,000 : Ft-cd 10 FC : ± ( 5 % + 40 FC )
Accessories Included:
- Instruction manual………………..1 PC
- Light probe………………………….1 PC
Optional Accessories:
- Carrying case, CA-52A
Mohon Tanyakan Stok Terlebih Dahulu Sebelum Order.
