SANWA RD700 DIGITAL MULTIMETER Original

Kategori: SANWA | Dilihat: 570 Kali

Harga: Rp 4.300.000

Beli

Tambah ke Wishlist

Pemesanan Juga dapat melalui :

Whatsapp SMS Telp

Kode Produk: SANWA RD700 Stok Tersedia - 18-08-2026

Detail Produk

SANWA PC7000 DIGITAL MULTIMETER

SANWA RD700 DIGITAL MULTIMETER adalah sebuah digital multimeter (multitester) portabel buatan Jepang yang dirancang khusus untuk pengukuran tingkat presisi tinggi pada sirkuit arus lemah, peralatan elektronik rumah tangga, perangkat komunikasi kecil, serta pengecekan baterai. Perangkat ini sangat populer di kalangan teknisi berkat akurasi dasarnya yang mencapai 0.3%.

Feature SANWA RD700 Digital Multimeter :

4000 Count display with backlight
0.3% Accuracy
Capacitance measurement
K type temperature measurement
Frequency measurement
ADP function (for current sensor)
Max recording measurement
Range hold, Data hold, and Relative function
Continuity confirmed by the buzzer
Auto and Manual range selection
Alarm for improper test lead insertion to current terminal
Auto power off: Turns off after 30 minutes of no operation
Protective holster with wall hanger and lead holder
Tilt stand

Specification SANWA RD700 Digital Multimeter :

RD700	Measuring range	Best accuracy	Resolution	Input impedance
DCV	400m/4/40/400/1000V	±(0.3%+4)	0.1mV	10M～1000MΩ
ACV	400m/4/40/400/1000V	±(1.5%+5)	0.1mV	10M～1000MΩ
DCA	400μ/4000μ/40m/400m/4/10A	±(1.2%+3)	0.1μA
ACA	400μ/4000μ/40m/400m/4/10A	±(1.5%+4)	0.1μA
Resistance	400/4k/40k/400k/4M/40MΩ	±(0.6%+4)	0.1Ω
Capacitance	500n/5μ/50μ/500μ/3000μF	±(2.5%+6)	0.1nF
Temperature	-20°C～300°C	±(2%+3)	1°C
Frequency	50Hz～1MHz	±(0.5%+4)	0.01Hz
Continuity	Buzzer sounds at between 20Ω and 120Ω. Open voltage:Approx.0.4V
Diode test	Open voltage:approx.1.6V

Display	numeral display 4000(Hz:9999, capacitance:5000)
Sampling rate	3 times/sec.(Hz:2 times/sec.)
Bandwidth	50～500Hz
Fuse	12.5A/500V IR20kA Φ6.3×32mm 0.63A/500V IR50kA Φ6.3×32mm
Battery	6F22(9V)×1
Size/Mass	H179×W87×D55mm/460g（including holster)
