Radio ICOM IC-M220 Marine Original
Radio ICOM IC-M220 Marine VHF Transceiver
Radio ICOM IC-M220 Marine adalah Radio Marine berkualitas premium yang memberikan audio sangat jelas dan mudah didengar. Dilengkapi dengan DSC kelas D terintegrasi dengan penerima CH70 khusus, radio ini memudahkan Anda untuk berkomunikasi di laut.
Other Features Radio ICOM IC-M220 Marine
Common NMEA interface for external GPS/NAV connection
MA-500TR Class B AIS transponder compatible
Tag scan and favorite channel functions
Dual/tri-watch function for monitoring CH16 and/or call channel
Priority scan function
Display and keypad backlighting
External speaker connection
Weather channel with weather alert
General Radio ICOM IC-M220 Marine
| Frequency range | TX | 156.025–157.425 MHz |
|---|---|---|
| RX | 156.050–163.275 MHz | |
| CH70 | 156.525 MHz | |
| Usable channels | USA, CAN, INT, WX channels | |
| Type of emission | 16K0G3E (FM), 16K0G2B (DSC) | |
| Power supply requirement | 13.8 V DC nominal (11.7–15.9 V DC) |
|
| Current drain (at 13.8 V DC) |
TX 25W output | 5 A |
| RX AF max. | 1.2 A | |
| Operating temperature range | –20°C to +60°C; –4°F to +140°F | |
| Antenna impedance | 50 Ω(SO-239) | |
| Dimensions (W×H×D) (Projections not included) |
156.5×66.5×110.1 mm; 6.2×2.6×4.3 inch |
|
| Weight (approx.) | 700 g; 1.5 lb (with HM-237B) | |
| NMEA formats | Input | RMC, GGA, GNS, GLL, VTG |
| Output | DSC, DSE, RMC, GSA, GSV | |
Spesifikasi Icom IC-M220
| GENERAL | |
| Frequency range | TX: 156.025–157.425 MHz |
| RX: 156.050–163.275 MHz | |
| CH70: 156.525 MHz | |
| Usable channels | USA, CAN, INT, WX channels |
| Type of emission | 16K0G3E (FM), 16K0G2B (DSC) |
| Power supply requirement | 13.8 V DC nominal |
| (11.7–15.9 V DC) | |
| Current drain | TX 25W output: 5 A |
| (at 13.8 V DC) | RX AF max.: 1.2 A |
| Operating temperature range | –20°C to +60°C; –4°F to +140°F |
| Antenna impedance | 50 Ω(SO-239) |
| Dimensions (W×H×D) | 156.5×66.5×110.1 mm; |
| (Projections not included) | 6.2×2.6×4.3 inch |
| Weight (approx.) | 700 g; 1.5 lb (with HM-237B) |
| NMEA formats | Input: RMC, GGA, GNS, GLL, VTG |
| Output: DSC, DSE, RMC, GSA, GSV | |
| TRANSMITTER | 25 W, 1 W |
| Output power (at 13.8 V DC) | ±5 kHz |
| Max. frequency deviation | ±5 ppm |
| Frequency tolerance | Less than –60 dBc |
| Spurious emissions | |
| RECEIVER | |
| Sensitivity | Main: -13 dBµ typ. (12 dB SINAD) |
| DSC: -5 dBµ emf typ. (1% BER) | |
| Squelch sensitivity | Less than –10 dBμ |
| Adjacent channel | Main: More than 68 dB |
| selectivity | DSC: More than 68 dBμ emf (1% BER) |
| Intermodulation | Main: More than 63 dB |
| DSC: More than 55 dBμ emf (1% BER) | |
| Sensitivity | –14 dBμ typ. (at 12 dB SINAD) |
| Hum and noise | More than 40 dB |
| Audio output power | 4.5 W typical |
| (at 10% distortion with a 4 Ω load) |
Applicable IP Rating
| Ingress Protection Standard | |
| Water | IPX7 (Waterproof protection) |
Radio ICOM IC-M220 Marine[/caption]
