Fusion Splicer INNO VIEW 8 Pro
Fusion Splicer INNO View 8 Pro – Premium Active Core Alignment
INNO View 8 Pro Fusion Splicer mengadopsi desain produk yang inovatif, sehingga dapat memberikan pengalaman penyambungan yang belum pernah terjadi sebelumnya kepada pelanggan. Desain produk yang sederhana namun trendi, struktur internal yang canggih, dan daya tahan yang andal membuat penyambung cocok untuk lingkungan operasi apa pun.
[caption id="attachment_6804" align="alignnone" width="150"]
Fusion Splicer INNO VIEW 8 Pro[/caption]
VIEW8 PRO adalah splicer core-alignment premium dengan menawarkan efisiensi kerja maksimum melalui mode cepat waktu sambungan 6 detik dan waktu pemanasan 9 detik.
Fusion Splicer Inno View-8 Pro adalah Splicer Fusion Penyelarasan Inti Premium dengan sistem operasi & manajemen berbasis Cloud.
Inno View-8 Pro merupakan splicer dengan spesifikasi tertinggi di dunia, menawarkan efisiensi kerja maksimum melalui mode cepat waktu sambungan 6 detik dan waktu pemanasan 9 detik.
Solusi berbasis cloud yang inovatif ini dirancang untuk menciptakan penyambungan dan pengalaman kerja yang paling canggih dan paling tidak rumit yang pernah ada.
Features Inno View-8 Pro
- Built-in IoT Module for Mobile Data Communication,
- Ultra-High Battery Capacity
- Precise Fibre Core Alignment Technology,
- Active Asset & Work Management Platform,
- User Friendly Interface with Built-in Videos,
- 5″ Colour LCD Touch Screen,
- High Definition CMOS
- Advanced Multi-Control Industrial CPU for motors
Specifications Fusion Splicer Inno View-8 Pro
Specifications
| Model | VIEW8PRO |
| Fiber Alignment Mode | Core Alignment |
| Number of Fiber | Single |
| Applicable Fibers | SM (G.652 & G.657) / MM (G.651) / DS (G.653) / NZDS (G.655) / CS (G.654) / EDF / BIF |
| Cladding Diameter | 80 – 150µm |
| Coating Diameter | 100 – 3000µm |
| Cleave Length | 5 – 16mm |
| Typical Splice Loss*¹ | SM: 0.01dB / MM: 0.01dB / DS: 0.03dB / NZDS: 0.03dB / G.657: 0.01dB |
| Return Loss | >>60dB |
| Estimated Splice Loss | Available |
| Splice Time*² | Quick mode: 6 sec. (AVG.) / SM Auto mode: 8 sec. (AVG.) |
| Splice Mode | Max. 128 modes |
| Heating Sleeve | 20 – 60mm |
| Heating Time*³ | 9 sec. (45mm, slim 60mm), 15 sec. (60mm) |
| Heating Mode | Max. 32 modes |
| Tension Test | 1.96 – 2.25N |
| Dimension | 143 (W) x 158 (D) x 162 (H) mm (with rubber bumper) 130 (W) x 157 (D) x 150 (H) mm (without rubber bumper) |
| Weight | 2.78kg (with battery) / 2.12kg (without battery) |
| White LED | 2 White LEDs |
| Monitor | 5.0” Color LCD display, Full touch screen |
| Fiber View | X, Y, XY, X/Y |
| Magnification | 320 – 520x |
| Result Storage | 10.000 Splice data / 10.000 Splice image |
| Power Supply | AC Input 100 – 240V, DC Input 9 – 14V |
| Terminal | USB Type C / Nano SIM |
| Battery Capacity*⁴ | LBT-30, Typical usage: 355 cycles / Power save usage: 450 cycles |
| Electrode Life*⁵ | 5500 ARC Discharges |
| GPS | Available |
| Operating Condition | Altitude: 0 – 5000m Humidity: 0 – 95%, non-dew Temperature: -10 to 50°C Wind: up to 15m/sec |
| Storage Condition | Humidity: 0 – 95%, non-dew Temperature: -20 to 60°C |
| Environment Test | Water Resistance: IPx2 Shock Resistance: Drop from 76cm Dust Resistance: IP5X |
Standard Package:
| Inno | VIEW-8 PRO | |
| Cleaver | V10 PRO | |
| Fiber Holder | FH-45 | |
| SOC Holder | SH-SOC-R | |
| SOC Heater Cover | HTS-SOC-04 | |
| AC Adapter | JS-180300 | |
| Cooling Tray | CG-22 | |
| Electrode | E-70 | |
| Battery Pack | LBT-30 | |
| Power Cable | ACC-25 | |
| Carrying Case | ICC-55 | |
| Work Tray | IWS-06 | |
| Work Tray Bolt (M6*8) | WTB-01 (2 each) | |
| Shoulder Strap | ST-01 (2 each) | |
| USB Cable | USB-7P | |
| Quick Reference |
Mohon Tanyakan Stok Terlebih Dahulu Sebelum Order.
