Aditeg AM-3125S Digital Insulation Tester 5000V Original
Aditeg AM-3125S Digital Insulation Tester 5000V
CV.MITRA LASER menjual Aditeg AM-3125S Digital Insulation Tester 5000V dengan harga murah ekonomis dan terpercaya.
Features Aditeg AM-3125S Digital Insulation Tester :
Display : 84.8 x 59.8mm LCD display. Max. Display 1999.
Over range indicator : the MSD shows 1 when it is over range.
Alarm function : the meter will alarm automatically when the tested resistance is below the lower range and the reading is invalid.
Power supply : LR6 (1.5) x batteries.
low battery indication display.
Operation environment : temperature 0~40C, 30%RH - 85%RH
Specification :
Range
Output Voltage
2500V/5000V 10%
Short-Circuit Current 4mA
Insulated Resistance 2500V
2G : 0.05 - 1.999G(5%5digit)
20G : 0.5 - 19.99G(5%5digit)
200G : 5.0 - 199.9G(10%5digit)
Insulated Resistance 5000V
2G : 0.05 - 1.999G(5%5digit)
20G : 0.5 - 19.99G(5%5digit)
200G : 5.0 - 199.9G(10%5digit)
Voltage Measurement AC750V(5%5digit)
Jack Position
Insulated Resistance : L, E AC750V : ACV G
ACV750V Input impedance : 1M.
ACV750V Frequency response : (50 ~ 200)Hz
termasuk batere AA (6 pcs)
user manual
test lead
Mohon Tanyakan Stok Terlebih Dahulu Sebelum Order.
